05 - 2011/02/09 11:15:50  PREVIOUS NEXT
This shows my water trap ahead of the gear pump. The first filter housing is empty, no filter element, this creates a low spot in the line for large chunks and water to get captured. The second filter housing has a paper element and protects the pump from too much junk. I typically drain water from these traps each day. Water that makes it past the traps will settle in the heater, where it is drained. Any remaining water will be captured by the centrifuge.
This shows my water trap ahead of the gear pump. The first filter housing is empty, no filter element, this creates a low spot in the line for large chunks and water to get captured. The second filter housing has a paper element and protects the pump from too much junk. I typically drain water from these traps each day. Water that makes it past the traps will settle in the heater, where it is drained. Any remaining water will be captured by the centrifuge.
